Set of 4 ferrules and 4 screws for bolting a neck onto a contoured solidbody when a flat neck attachment plate is impractical.
5/8″-diameter counterbored holes required.
The suggested 5/8″ diameter is slightly oversize to allow for finish thickness in the recess. Use a 15mm bit if you plan to fit the ferrule with no finish in the recess.
Screws are 11/64" (4.2mm) dia. x 1-1/2" (38mm) long Phillips ovalhead.
Popular high quality tuners with cast gear housings and maintenance-free sealed lubrication. Adjustable knob tension.The M6 Mini's have the same design features as full size M-6 tuners, but with compact housings and smaller knobs.• 14:1 ratio
• 10mm (13/32") diameter pegholes required
• Removable metal knobs
• Mounting screws, threaded hex bushings and washers included
• Set of 6
Installation TipsMounting screws: Pilot holes required. Installing delicate screws into hard wood requires great care and accuracy. Lubricate the screw threads with cutting lubricant (also wax or a bar of soap) to reduce friction and help them thread properly.
Official Floyd Rose L Shaped Fat Brass upgradable Sustain Blocks for Floyd Rose Tremolo units. Studies have shown that Mass = Sustain. The all new Fat Brass "L" shaped sustain blocks by Floyd Rose have been specifically designed to take advantage of the unused area under the tremolo arm. By incorporating an additional "L" shape of brass to the design of a stock sustain block, Floyd Rose has been able to utilize this previously unused space for additional mass which equates to more sustain and additional tonal qualities of brass.
Brass has been a much desired material for guitar luthiers dating back to the invention of the instrument; it is notorious for increasing warmth and clarity simultaneously, a rare combination. While greatly strengthening chord clarity and beefing up individual notes, it also greatly improves resonance, especially in the midrange of the instrument. All of these improvements are accompanied with the undeniably vintage sound and feel of this time-tested material.
Since this block is larger than a conventional sustain block, it can also limit upward travel of the tremolo and can be set to rest against the body in a blocked bridge configuration. For floating bridge setup this block may require some routing in the spring cavity.
